The difference between low-pressure and high-pressure injection molding comes down to how hard the machine pushes plastic into the mold, and that one difference decides which parts each process is good at. High-pressure molding packs solid plastic in under heavy force, which suits small, thin-walled, detailed parts. Low-pressure molding, which includes structural foam, structural web, and gas-assist, fills the mold gently, which suits large, thick-walled, rigid parts.

We run both at 20/20 Custom Molded Plastics, on presses from smaller tonnage up to 8,000 tons, so we can point a part to whichever process actually fits it rather than to whatever we happen to have open. Here is how the two compare and how to tell which one your part needs.

What “pressure” actually means here

In high-pressure injection molding, the machine injects molten plastic fast and then holds it under heavy pressure while the part cools. Holding the mold shut against that force takes a lot of clamp tonnage, and the bigger the part, the more tonnage you need.

Low-pressure molding works differently. In heavy manufacturing, low pressure means the structural foam family, where a small amount of nitrogen gas (or a foaming agent) is mixed into the melt. As the material enters the mold, the gas expands and helps push it out to fill the cavity, so the machine does not have to force it in. Cavity pressure often sits in the low hundreds of psi, a fraction of high-pressure molding, and the clamp tonnage needed drops with it. That is what makes it practical to mold very large parts. (You will also see “low pressure” used for encapsulating electronics, which is a different thing. Here we mean large industrial parts.)

The low-pressure toolkit

Low pressure is not one process. It is a family, and each member has a niche:

• Structural foam: the workhorse for large, rigid parts with a solid skin and a foamed core. Best all-around choice for big, thick-walled components.
• Structural web: similar low-pressure approach that produces a smoother surface on large panels and covers, without swirls.
• Gas-assist: nitrogen routed through thicker sections to hollow them out, which lets you run heavy ribs and bosses and stiffen a part without adding solid mass.

We run all three, which means a large part can be matched to the exact low-pressure method that suits its geometry. For the mechanics of the core process, see our companion post, What Is Structural Foam Molding?

When high-pressure molding is the right call

High-pressure molding is the better process when the part is on the smaller side and the details matter. The heavy packing pressure fills thin walls and fine features cleanly, holds tight tolerances, and produces a smooth, glossy finish straight off the press, which is why it is the standard for consumer-facing parts.

The trade-off shows up as parts get bigger. High-pressure molds have to be cut from hardened tool steel to survive the forces, and machining a large steel mold is a major upfront cost and a long lead time. For a small part that is routine. For a very large part it can be the thing that stalls the project.

When low-pressure molding wins

Low pressure takes over when the part is large, thick-walled, and needs to be rigid:

• It holds big surfaces flat. Low pressure means less molded-in stress, so large, flat panels come out dimensionally stable instead of warped.
• It allows reduced sink marks on thick sections. The expanding gas pushes outward as the part cools, so thick walls, heavy ribs, and bosses do not pull in and leave visible marks.
• It runs big parts at lower tonnage. Because the gas does the packing, large parts can be molded without the enormous clamp force high-pressure molding would need at that size.
• It makes parts lighter. The foamed core cuts part weight by roughly 10 to 20 percent versus a solid part, which lowers shipping and handling costs.
• It is more forgiving on materials. The thicker walls and lower pressure make it easier to run recycled resin, so post-consumer and post-industrial regrind can often go into the part.
• It opens the door to lower-cost tooling. Because the pressure is low, tooling is usually made from aluminum rather than hardened steel, which is faster to machine and less expensive, though the right tooling approach depends on the part and the volumes.

How to choose

A quick way to sort it out:

• Consider high-pressure if the part is small to medium, has thin walls, needs tight tolerances or fine detail, or has to come off the press with a glossy, cosmetic finish, especially at high volumes.
• Consider low-pressure if the part is large, thick-walled, or load-bearing, if warp and sink marks are a risk, if weight matters, or if the cost of a big steel mold is hard to justify.

Plenty of parts sit in the middle, and that is where a molder that runs both processes is worth talking to before you commit tooling.

One partner for both processes

Because we run the full range, low-pressure structural foam, structural web, and gas-assist alongside high-pressure injection molding, we are not tied to one answer. We would rather match your part to the right process. On the low-pressure side we have the press capacity for large work, up to 8,000 tons plus a full range of smaller presses, across plants in Holiday City, Ohio; Bluffton, Indiana; and Covington, Georgia. We give design-for-manufacturability feedback early, before tooling is committed, so the process decision is made with your part in front of us.

Send us your part design and our engineers will review the geometry, recommend the process that fits, and put together a molding estimate. Contact 20/20 Custom Molded Plastics to start.

Frequently Asked Questions

What is the difference between low-pressure and high-pressure injection molding?

High-pressure molding forces solid plastic into a steel mold under heavy pressure and holds it there while it cools, which suits small, detailed, thin-walled parts. Low-pressure molding, such as structural foam, fills the mold at a fraction of that pressure using an expanding gas, which suits large, thick-walled, rigid parts and needs much less clamp tonnage.

Is low-pressure molding weaker than high-pressure molding?

No. A structural foam part has a solid outer skin over a foamed core, which gives it a high stiffness-to-weight ratio and makes it well suited to large, load-bearing parts. A high-pressure part is fully dense, so it holds thinner walls and finer detail. The stronger choice depends on the part.

Which process is cheaper?

It depends on the part. For large parts, low pressure often wins on upfront cost because it can use lower-cost aluminum tooling and run on lower-tonnage presses. For small, high-volume parts, high-pressure molding usually wins because its faster cycle times lower the per-part cost.

When should I use low-pressure molding?

Use low pressure when the part is large, thick-walled, or load-bearing, when you need to avoid warp and sink marks, or when weight and tooling cost matter. Common examples are pallets, bins, enclosures, and large equipment housings.
